Merits Wide Seat Raptor Mobility Scooter

Add to Wishlist

New and improved wide seat (80 x 46 x 51cm), fully adjustable leather-feel seat, allowing maximum rider comfort.
Looped handlebars offer comfortable throttle operation.
4 wheel adjustable suspension system allowing for more rider control and comfort.
Large 14” wheels which provide grater ground clearance.
Larger 4 pole motor and larger controller, delivering more power for climbing steep inclines.
Built-in half speed safety switch which operates automatically when turning to provide extra safety.
Separate emergency braking system for added security.
New easy to access 12 volt socket.

Add to Wishlist

Category: Mobility Scooters

New sporty streamline design
Full suspension system with shock absorbers which delivers a smooth, comfortable ride
Large 14î wheels which provide greater ground clearance
Modern LED lighting system delivers a brillian light with less power consumption
Digital LCD dashboard display: time display, battery gauge, temperature, maintenance messages, speed display and odometer
Extra storage space beneath tiller
Half speed safety switch which operates automatically when turning to provide extra safety
With Merits 4PT (4 pole technology) and large controller & motor delivering much more power for climbing steep driveways and hills
With new easy to access 12-volt socket
Available in wide seat version

Dimension with Pallet: Length 162cm x Width 77cm x Height 96cm

Max Speed 10kph/6.25mph
Range 40-50km/26-32mi
Turn Radius 167cm/65.7″
Ground clearance 10cm/4″
Motor DC 24V, 650W (Rating)/
2200W (Max)
Controller Rhino 160A
Battery 12V/60-80A/H x 2pcs
Charger 6A off-board
Gradient 8∞
Front Wheel 14″ pneumatic
Rear Wheel 14″ pneumatic
Brake intelligent, regenerative,
electromagnetic brakes

Rapture Brochure
